| SPECIFICATION 規格
/ 機型 MODEL |
FB-10B |
FB-13B |
FB-17B |
FB-19B |
FB-24B |
FB-30B |
FB-36B |
 .FORGING
STATION 模數 |
(mm) |
|
3S |
4S |
3S |
4S |
3S |
4S |
3S |
4S |
3S |
4S |
3S |
4S |
4S |
| CUT-OFF
DIA.MAX 最大切斷直徑. |
(mm) |
|
8 |
10 |
12 |
15 |
18 |
23 |
29 |
| OUT-OFF
LENGTH MAX. 最大切斷長度 |
(mm) |
|
70 |
100 |
110 |
115 |
140 |
200 |
270 |
320 |
| KICK-OUT
LENGTH MAX. 後托頂出長度 |
(mm) |
|
60 |
80 |
90 |
90 |
125 |
175 |
240 |
390 |
| PUNCH
KICK-OUT LENGTH MAX. 前托頂出長度 |
(mm) |
|
12 |
16 |
20 |
20 |
25 |
30 |
35 |
60 |
| CUT-OFF
QUILL(DIA. X LENGTH) 切模 |
(mm) |
|
25x46 |
35x56 |
40x60 |
46x80 |
60x100 |
75x120 |
90x140 |
| MAIN
DIE HOLE(DIA.X LENGTH) 母模 |
(mm) |
|
50x65 |
60x85 |
60x105 |
80x105 |
95x123 |
100x195 |
125x240 |
160x294 |
| DIES
PLTCH 母模中心距離 |
(mm) |
|
60 |
87 |
93 |
114 |
126 |
138 |
174 |
| PUTCH
HOLE(DIA.X LENGTH) 公模束 |
(mm) |
|
40x80 |
45x90 |
50x102 |
60x120 |
75x165 |
90x190 |
105x232 |
| PAM
STROKE 主滑板行程 |
(mm) |
|
120 |
140 |
150 |
160 |
200 |
380 |
360 |
440 |
| FORGING
POWER 壓造力 |
(Ton) |
|
20 |
30 |
40 |
50 |
60 |
75 |
80 |
100 |
140 |
160 |
200 |
220 |
320 |
FRODUCTS
產品 |
| SIZE 尺寸 |
(mm) |
|
1/4(M6) |
5/16(M8) |
3/8(M10) |
1/2(M12) |
5/8(M16) |
3/4(M20) |
1(M24) |
| MAX.LENGTH 最長長度 |
|
50 |
65 |
75 |
75 |
100 |
150 |
200 |
250 |
MIN.LENGTH(mm)
最短長度 |
HEX.外六角螺絲
SOCKET強力螺絲 |
12 |
14 |
16 |
16 |
20 |
25 |
40 |
60 |
| MAX.OUTPUT 每分鐘最大產能 |
(pcs/minute) |
|
250 |
210 |
210 |
180 |
180 |
150 |
150 |
100 |
80 |
60 |
| MAIN
MOTOR 主馬達 |
(Hp) |
|
10 |
15 |
15 |
20 |
20 |
30 |
40 |
50 |
75 |
75 |
100 |
100 |
125 |
| APPROX
WT 機械重量 |
(Ton) |
|
6 |
8 |
9 |
11 |
13 |
16 |
20 |
24 |
32 |
42 |
45 |
56 |
100 |
